0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter

0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter
0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter
0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter

Large Image :  0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter

Product Details:
Place of Origin: China,ShangHai
Brand Name: PULLNER
Certification: ISO9001
Model Number: PLZ-PPL
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: To be negotiable
Packaging Details: Carton box after poly bag, 50pcs per carton.
Delivery Time: Eight working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100pcs per day

0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter

Description
Maximum Operating Temperature: 80℃ Mosit-heat Sterilization: 121°C/30min
Maximum Operating Differential Pressure: 4bar@25°C,2.6bar@25°C Flowing Hot Water Sterilization: 85°C/30min
Outside Diameter: 68.5mm Filtration Area: 0.4-0.7m³
Brand: Pullner Manufacture Place: China
High Light:

RO Water Treatment PP Filter Cartridge

,

0.1um Pleated Filter Cartridge

,

Industrial Pleated Filter Cartridge

                                  Pleated PP Filter Cartridge for security filter of RO water treatment


This series pleated filter cartridges are made of imported Polypropylene (PP) membrane. high flow rate and high dirt holding capacity, it has excellent ability to filter out impurities,especially for viscous,contaning colloidal liquid filtration,which is widely used in various fields such as pharmaceutical, electronics, chemical industry, food and beverage, etc. Broad compatibility and can filter most acids, alkalis and solvents.



0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 00.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 1
Material Construction


Filter MediaSupport/DrainageEnd Caps/Core/Cage
PolypropylenePolypropylenePolypropylene


Filter Performance


Micron1-20um
Filter area0.4-0.7m²
Maximum Operating Temperature80
Maximum Operating Dfferential Pressure

4bar@25°C
2.6bar@25°C

Flowing

hot water sterilization

85°C/30min


Flow Rate and Filtration Area

Size
(Diameter*Length)

Design Flow
(m3/hr)

Maximum Flow
(m3/hr)

Filtration Area
(㎡)

6"*20"15402.6
6"*40"30805.2
6"*60"451207.8





0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 2

0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 3
Security filter of RO water treatment;
Fermentation air pre-filter;
Beer,wine,liquor and other food and beverage clarification and filtration;
Mineral water pre-filter and sophisticated filter;
Pre-filter of infusion,biological products and fermentataion broth;
Optical mirror resin monomer filter.

0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 4
0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 5
































0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 6





0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 7

Shanghai Pullner Filtration Technology Co., Ltd. was established in May 2011 with a registered capital of 26 million yuan. It has a 100,000-level purification workshop of 3,000 m² and a local thousand-level purification laboratory. It is a research and development, production and sales of microporous membrane filtration equipment, filtration system in one of the well-known enterprises.
The company's products are mainly used in Microelectronics, Fine chemicals, New energy, Seawater desalination, Biotech, Latoratory and other fields. Covering Liquid crystal panels, Semiconductor chips, High-purity chemicals, Raw materials, Condensate filtration, Reclaimed water reuse more than a dozen industries.

0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 8

0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 9

0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 10




0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 11 0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 12 0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 13

Our company has ISO19001, ISO14001, ISO45001 certificates, we are high-tech enterprise with multiple patent certificates. Approval vendor of Saudi Aramco.


0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 14

0.1 - 20um Series PP Pleated Filter Cartridge For RO Water Treatment Security Filter 15
