|Product Name:||FRP 4*40 Fiberglass Membrane Filter Housing||Surface Treatment:||Polished & Sandblast|
|Seal Type:||O Type Ring||Design Pressure:||1200PSI(8.3MPa)|
|Height:||40" (1016mm) Or 60"(1524mm)||Filter Cartridge Size:||Diameter 6" (152mm)|
|Bursting Pressure:||7200PSI(49.8MPa)||Inlet & Outlet Type:||Internal Thread/Flange|
|Seal O-ring:||NBR/EPDM/Viton||Temperature Range:||-10℃ To 66 ℃|
|Water Purification Outlet:||1'' NPTF Thread Interface||Primary/thick Nozzle:||1.5''/2''/2.5'' Clamp Interface|
|Application:||Water Purification||Diaphragm Element:||1-8core|
SWRO Desalination RO Prefiltration Filter Housing,
8080 Fiberglass Membrane Cartridge Filter Housing,
FRP Cartridge Filter Housing 8 Inch
8 inch 8040 8080 Fiberglass Membrane Cartridge Filter Housing SWRO Desalination RO Prefiltration
FRP Series Horizontal Single FRP High Flow Cartridge Filter Housing offer a cost effective, easy to use cartridge filter housing solution. It's suitable for 40" and 60" high flow pleated filter, which means it has higher flow rate than traditional filter cartridges. Both end caps adopt PA material and sealed with EPDM O-ring, which have high sealing performance and easy to assemble. Comparing to stainless steel high flow filter housing, FRP series FRP housing can be used more widely, has smaller footprint and are more economic.
Besides the strong anti-corrosion performance, high-strength FRP high flow filter housing has the advantages of simple assembly, flexible design, reliable operation and easy replacement of filter elements, which makes it popular in various applications, such as brackish water reverse osmosis prefiltration, sea water desalination, food and beverage, power generation and water treatment system.
Features and Benefits
• Unit type design, convenient combination, high-cost performance;
• The membrane shell adopts numerical control winding technology, with high smoothness and easy cleaning.
• Side-in and side-out inlet and outlet design makes it easier to remove the filter cartridge;
• The equipment is small in size and beautiful in appearance. Vertical/horizontal can be selected according to the site working conditions;
• The branch has a valve design, which can replace the filter cartridge without stopping the machine;
|Strap Bolt||Stainless Steel|
|Design Pressure||0.6MPa / 1.0MPa|
|Filter Cartridge Number||1|
|Filter Cartridge Length||1028mm/1540mm|
|Filter Cartridge Diameter||152mm|
|Liquid Flow Direction||Inside to Outside (Internal Pressure Type)|
P-FRP150 01 20 K65 S Z
|Code||Filter Number||Filter Length||Inlet / Outlet Connection||Sealing Material||Design Pressure|
|P-FRP150||01 (1 Round)||20 (20")||K65 (DN65)||S (Silicone)||Z (0.6MPa)|
|40 (40 ")||K80 (DN80)||E (EPDM)||O (1.0MPa)|
|60 (60 ")||K100 (100)||V (Viton)||C (Customize)|
