Product Details:
|
| Filter Cartridge Size: | Diameter 6" (152mm) | Surface Treatment: | Polished & Sandblast |
|---|---|---|---|
| Seal Type: | O Type Ring | Inlet & Outlet Type: | Internal Thread/Flange |
| Seal O-ring: | Silastic/NBR/EPDM/Viton | Packaging Method: | Export Standard Wooden Box |
| Height: | 40" (1016mm) Or 60"(1524mm) | Design Pressure: | 1200PSI(8.3MPa) |
| Bursting Pressure: | 7200PSI(49.8MPa) | Color: | White; Blue |
| Medium: | Water | Temperature Range: | -10℃ To 66 ℃ |
| Primary/thick Nozzle: | 1.5''/2''/2.5'' Clamp Interface | Application: | Water Purification |
| Product Name: | FRP 4*40 Fiberglass Membrane Filter Housing | Water Purification Outlet: | 1'' NPTF Thread Interface |
| Diaphragm Element: | 1-8core | ||
| High Light: | 152mm FRP Filter Housing,RO Prefiltration Fiberglass Cartridge Filter Housing,SWRO Desalination Membrane Cartridge Filter Housing |
||
SWRO Desalination RO PrefiltrationFiberglass Membrane Cartridge Filter Housing For Sea Water Desalination
General Description:
The P-FRP150 series FRP filter housing are especially suitable for the filtration of corrosive liquids such as sea water desalination, which effectively solves the problems of corrosion, leakage and degumming of traditional filters. The filter housing adopts a single filter cartridge design, which can be freely combined with ultrafiltration and reverse osmosis systems, and can also be set into several filter units according to the site environment, which has strong adaptability to the site environment.The high flow solution of FRP cartridge housing can help to save much space and equipment cost, it is a very popular water filtration system.
Features and Benefits
•Unit type design, convenient combination, high cost performance;
•The membrane shell adopts numerical control winding technology, with high smoothness and easy cleaning.
• Side-in and side-out inlet and outlet design makes it easier to remove the filter cartridge;
•The equipment is small in size and beautiful in appearance. Vertical/horizontal can be selected according to the site working conditions;
• The branch has a valve design, which can replace the filter cartridge without stopping the machine;
Application
RO-Prefiltration
Water Processing
Power Generation
Food and Beverage
Sea water desalination
Industrial water treatment
Material
| Filter Housing | FRP |
| Water Intake | FRP |
| Saddle | Rubber |
| Strapping | Stainless Steel/Rubber/Brass |
| Strap Bolt | Stainless Steel |
| Sealing | EPDM/Silicone/Fluorine Rubber |
Operating Parameters
| Design Pressure | 0.6MPa / 1.0MPa |
| Operating Temperature | -10℃~65℃ |
| Filter Cartridge Number | 1 |
| Filter Cartridge Length | 1028mm/1540mm |
| Filter Cartridge Diameter | 152mm |
| Liquid Flow Direction | Inside to Outside (Internal Pressure Type) |
| Design Flow | 35m³/h |
Ordering Information
P-FRP150 01 20 K65 S Z
| Code | Filter Number | Filter Length | Inlet / Outlet Connection | Sealing Material | Design Pressure |
| P-FRP150 | 01 (1 Round) | 20 (20") | K65 (DN65) | S (Silicone) | Z (0.6MPa) |
| 40 (40 ") | K80 (DN80) | E (EPDM) | O (1.0MPa) | ||
| 60 (60 ") | K100 (100) | V (Viton) | C (Customize) | ||
| T (PTFE) |
Product details
Company profile:
Shanghai Pullner Filtration Technology Co., Ltd. was established in May 2011 with a registered capital of 26 million yuan. It has a 100,000-level purification workshop of 3,000 m² and a local thousand-level purification laboratory. It is a research and development, production and sales of microporous membrane filtration equipment, filtration system in one of the well-known enterprises.
The company's products are mainly used in Microelectronics, Fine chemicals, New energy, Seawater desalination, Biotech, Latoratory and other fields. Covering Liquid crystal panels, Semiconductor chips, High-purity chemicals, Raw materials, Condensate filtration, Reclaimed water reuse more than a dozen industries.
