PVDF Membrane Pleated Filter Cartridge for High-Purity Gas Filtration with 0.22 µm Rating and Thermally Welded Construction

All Products

High Flow Filter Cartridge

(172)

Pleated Filter Cartridge

(88)

Membrane Filter Cartridge

(59)

PP Pleated Filter

(38)

High Temperature Water Filter

(29)

Condensate Polishing Filter

(36)

String Wound Filter Cartridge

(36)

Melt Blown Filter Cartridge

(19)

Stainless Steel Filter Cartridge

(30)

Stainless Steel Filter Housing

(28)

Power Plant Filter Cartridge

(13)

Microelectronics Filter

(15)

Beverage Filter Cartridge

(17)

Pharmaceutical Filters

(15)

FRP Filter Housing

(10)

New Energy Filter Cartridges

(16)
Certification
china Shanghai Pullner Filtration Technology Co., Ltd. certification
china Shanghai Pullner Filtration Technology Co., Ltd. certification
Customer Reviews
We use filters in one of Turkey’s largest food factory. We use it as a reverse osmosis pre-filter, we are very satisfied with your product, Miss Lucy helped us a lot, provided very quick returns to our problem. We will use it in our new factory in Romania, I also recommend it to our customers who ask.

—— Jose

PULLNER are good business partner. Nice products with reasonable price, best service, we cooperated more than 5 years.

—— Nisa

In our facility, Pullner's PP Capsule Filter is installed upstream as a pre-filter. It provides stable filtration, reduces downstream load, and supports smoother RO operation. We also appreciate Miss Lucy—her quick communication and problem-solving made the whole process easy. We’ll keep using this product and recommend it to customers in India

—— Shubh

Pullner's high flow filter cartridge has a good quality, we use them a lot and mainly applied in power plant water filtration. The cartridge shows strong mechanical strength and reliable performance. we will continue work with Pullner in future

—— Thomas Ral

I'm Online Chat Now

PVDF Membrane Pleated Filter Cartridge for High-Purity Gas Filtration with 0.22 µm Rating and Thermally Welded Construction

PVDF Membrane Pleated Filter Cartridge for High-Purity Gas Filtration with 0.22 µm Rating and Thermally Welded Construction
PVDF Membrane Pleated Filter Cartridge for High-Purity Gas Filtration with 0.22 µm Rating and Thermally Welded Construction
PVDF Membrane Pleated Filter Cartridge for High-Purity Gas Filtration with 0.22 µm Rating and Thermally Welded Construction PVDF Membrane Pleated Filter Cartridge for High-Purity Gas Filtration with 0.22 µm Rating and Thermally Welded Construction PVDF Membrane Pleated Filter Cartridge for High-Purity Gas Filtration with 0.22 µm Rating and Thermally Welded Construction PVDF Membrane Pleated Filter Cartridge for High-Purity Gas Filtration with 0.22 µm Rating and Thermally Welded Construction PVDF Membrane Pleated Filter Cartridge for High-Purity Gas Filtration with 0.22 µm Rating and Thermally Welded Construction

Large Image :  PVDF Membrane Pleated Filter Cartridge for High-Purity Gas Filtration with 0.22 µm Rating and Thermally Welded Construction

Product Details:
Place of Origin: China
Brand Name: Pullner
Certification: ISO9001,ISO14001,ISO45001
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiable
Packaging Details: export standard packaging
Delivery Time: 5-10 working days
Payment Terms: ,L/C,D/A,D/P,T/T,Western Union
Supply Ability: 100pcs /day
Contact Now

PVDF Membrane Pleated Filter Cartridge for High-Purity Gas Filtration with 0.22 µm Rating and Thermally Welded Construction

Description
Highlight:

0.22 µm PVDF Membrane Filter Cartridge

,

High-Purity Gas Filtration Pleated Filter Cartridge

,

Thermally Welded Microporous Filter Cartridge

PVDF Membrane Microporous Pleated Filter Cartridge
PVDF Membrane Microporous Pleated Filter Cartridge for Microelectronics & High-Purity Gas / Liquid Filtration (0.22 µm)
General Description
The PVDF membrane pleated filter cartridge is manufactured with imported high-quality natural hydrophobic PVDF membrane combined with advanced non-woven support layers. All adapters and end components are thermally welded without any adhesives, eliminating the risk of extractables or secondary contamination and ensuring excellent chemical purity. This cartridge is designed to meet the stringent requirements of microelectronics, semiconductor, and high-purity process filtration, offering stable performance, long service life, and high reliability under demanding operating conditions.
Applications
  • High-purity gas filtration in the electronics and semiconductor industry
  • Clean and sterile gas filtration for aseptic packaging systems
  • Steam filtration and sterilization processes
  • Sterilizing filtration of oxidizing liquids and gases
  • Filtration applications in the petroleum and chemical industries
Features & Benefits
  • Naturally hydrophobic PVDF membrane, ideal for gas filtration applications
  • Modified hydrophilic membrane option available for liquid filtration
  • Wide chemical compatibility with pH range from 1 to 13 (up to 14)
  • Excellent high-temperature and oxidation resistance
  • Low differential pressure, high flow rate, and extended service life
  • Each filter cartridge is thoroughly rinsed with high-purity water before shipment to ensure cleanliness and consistency
Dimensions
  • Outer diameter: 2.7" (69 mm)
  • Lengths available: 10", 20", 30", 40"
Materials of Construction
Component Material
Filter medium PVDF membrane
Support / drainage layer Polypropylene
Center core / outer cage / end caps Polypropylene
Seal materials NBR, Silicone, EPDM, Viton
Filtration Performance
  • Micron ratings: 0.1 µm, 0.22 µm, 0.45 µm, 0.65 µm
  • Standard lengths: 10", 20"
  • Interception efficiency: 100%
  • Air flow rate: up to 107 CFM/cm²
  • Maximum operating temperature: 80 °C
  • Maximum differential pressure:
    • 0.42 MPa at 25 °C (forward flow)
    • 0.21 MPa at 25 °C (reverse flow)
  • Applicable pH range: 1-14
Application
PVDF Membrane Pleated Filter Cartridge for High-Purity Gas Filtration with 0.22 µm Rating and Thermally Welded Construction 0
Frequently Asked Questions
1. Q: Are you a trading company or a manufacturer?
A: We are a professional manufacturer of all kinds of filter cartridges, housings and filtration systems. We provide you the total filtration solutions with our many years experience in the industry.
2. Q: May I have samples?
A: Sure, of course. Sample cost can be refunded if you place formal orders in the future.
3. Q: Can you make customized products?
A: Yes, of course. if you can provide us detailed specifications or drawings. Our mission is make customer idea on the products and provide the customer satisfied solutions.
4. Q: Can I use our own designed package?
A: Yes, size, color, logo and packaging style all can be customized.
5. Q: What's your MOQ?
A: Normally, 100PCS/item. Any trial order which is less than MOQ is warmly welcomed. If you have a trial order, please feel free to contact us so that we can make some shipping recommendation for you to save the cost based on the quantity you need.
6. Q: I am a small business owner, Can I buy from you?
A: Yes, you are warmly welcomed. To grow with our customer is our goal. We would like to grow with you together.
