20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction

20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction
20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction
20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction 20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction 20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction 20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction 20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction 20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction 20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction 20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction 20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction

Large Image :  20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction

Product Details:
Place of Origin: Shanghai,China
Brand Name: Pullner
Certification: ISO19001, ISO14001, ISO45001
Model Number: PLZ-PPL
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Negotiable
Packaging Details: Individual packaged in carton box after poly bag.
Delivery Time: 7-10 work days
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 1000+PC+per week
Contact Now

20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction

Description
Highlight:

20" Nominal Rating Polypropylene Filter Cartridge

Product Overview
Model: PPL series
Type: PP Filter
Origin: China
Technical Specifications
Parameter Specification
Filter Medium Polypropylene (PP)
Support/Drainage Polypropylene (PP)
Core/Cage/End Cap Polypropylene (PP)
Outside Diameter 2.7" (68.5mm)
Length 10", 20", 30", 40"
Micron Rating 0.1um, 0.22um, 0.45um, 1um, 2um, 3um, 5um, 10um, 20um, 30um, 60um
Filtration Area 0.4-0.7m²
Max. Operating Differential Pressure ΔP≤0.35MPa at 25℃
Max. Operating Differential Pressure (Reverse) ΔP≤0.28MPa at 60℃
Sterilization Temperature 30 minute cycles @121℃
Max. Operating Pressure 4bar/21℃, 2.4bar/80℃
Material Construction
Filter Media: Polypropylene (PP)
Support/Drainage: Polypropylene (PP)
Cage/Core/End Caps: Polypropylene (PP)
Seal Material: Silicone, NBR, Viton, EPDM
Applications
  • Food and Beverage: Beer, wine filtration; juice and soda filtration; oral liquid filtration; additives, oil filtration
  • Water Treatment: Urban water supply, industrial water filtration; power plant condensate filtration
  • Metal Processing: Cutting fluid and coolant filtration; lubricating oil filtration
Packaging Details
Package Size: 62.50cm × 40.50cm × 41.00cm
Package Gross Weight: 17.000kg
Manufacturer Information
20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction 0
Shanghai Pullner Filtration Technology Co., LTD.
Established: 2013
Specialty: PP pleated filter cartridges, melt-blown filter cartridges, string wound filter cartridges, stainless steel filter cartridges
China Offices: Beijing, Guangzhou, Fujian, Sichuan, Guangxi, Yunnan, Xinjiang, Inner Mongolia, Shaanxi, Northeast China
Global Presence: UAE (Dubai), Malaysia (Kuala Lumpur), Russia
20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction 1
FAQ:
What is the brand name of this product?
The brand name is PULLNER.
What is the model number of this product?
The model number is PLZ.
Where is this product manufactured?
This product is made in China.
What is the main function of this product?
The main function of this product is to filter beverages.
What is the recommended usage time for this product?
The recommended usage time for this product is 6-12 months.
