5 inch 316L Stainless Steel Pleated Filter Cartridge Sintered Fiber Felt for High Temperature 480C Industrial Filtration

Large Image : 5 inch 316L Stainless Steel Pleated Filter Cartridge Sintered Fiber Felt for High Temperature 480C Industrial Filtration

Product Details:

Place of Origin:	Shanghai, China
Brand Name:	Pullner
Certification:	ISO 9001, ISO 14001, ISO 45001
Model Number:	PHSF

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece
Price:	Negotiable
Packaging Details:	Export standard packaging
Delivery Time:	5-7 working days for samples, 10-15 working days for bulk
Payment Terms:	T/T,L/C,Western Union,D/P,D/A
Supply Ability:	100 Pieces per Week

Contact Now

5 inch 316L Stainless Steel Pleated Filter Cartridge Sintered Fiber Felt for High Temperature 480C Industrial Filtration

Description

Filter Medium:	316L Stainless Steel Sintered Fiber Felt	Core/Outer Guard:	SUS 304/316L Porous Plate
End Caps:	SUS 304/316L	Filtration Rating:	5, 10, 15, 20, 25, 30, 40, 60 μm
Max Operating Temperature:	480°C	Max Differential Pressure:	5.0 Bar
Standard OD:	65 Mm	Length Options:	5, 10, 20, 30, 40 Inch
Porosity:	67% – 85%
Highlight:	Stainless Steel Sintered Fiber Felt , High Temperature Corrosion Resistant Filter , Large Filtration Area Pleated Design

PHSF 316L Stainless Steel Fiber Felt Pleated Filter Cartridge

Engineered for the toughest industrial filtration environments where extreme temperatures, aggressive chemicals, and high-pressure conditions challenge conventional filters.

5 inch 316L Stainless Steel Pleated Filter Cartridge Sintered Fiber Felt for High Temperature 480C Industrial Filtration

The PHSF series features all 316L stainless steel construction with sintered fiber felt media, shaped through a precision pleating process that maximizes surface area within compact housing dimensions. The graded pore structure — coarse upstream, fine downstream — delivers superior dirt holding capacity and significantly extended service intervals compared to disposable alternatives.

Key Features:

All 316L stainless steel construction — zero media migration, fully welded for absolute integrity
Maximum operating temperature: 480°C — ideal for steam, hot oil, and high-temperature process fluids
Superior corrosion resistance — handles aggressive acids, alkalis, solvents, and saltwater
High dirt holding capacity with graded pore depth filtration technology
Large filtration area through pleated design — higher flow rates with lower pressure drop
Cleanable and reusable — backwash compatible for extended service life
5.0 bar maximum differential pressure rating

Dimensions & Filtration Area:

Length	Filtration Area
5 inch (127 mm)	0.096 m²
10 inch (254 mm)	0.19 m²
20 inch (508 mm)	0.38 m²
30 inch (762 mm)	0.57 m²
40 inch (1016 mm)	0.76 m²

Technical Specifications

Core/Outer Guard	SUS 304/316L Stainless steel porous plate
Filter Medium	Upstream Support: 30 mesh or 40 mesh stainless steel wire mesh Filter net: Required accuracy of stainless steel wire mesh Downstream Support: 30 mesh or 40 mesh stainless steel wire mesh
End Caps	SUS 304/316L Stainless steel
Max. Operating Differential Pressure	5.0 bar
Max. Operating Temperature	480℃

Standard Dimensions

Standard OD	Standard Length	Filter Area
65mm Customized on request	5in. (127mm)	0.096 m²
65mm Customized on request	10in. (254mm)	0.19 m²
65mm Customized on request	20in. (508mm)	0.38 m²
65mm Customized on request	30in. (762mm)	0.57 m²
65mm Customized on request	40in. (1016mm)	0.76 m²

Material Properties

No.	Liquid Accuracy(um)	Gas Accuracy (um)	Porosity(%)	Average Air-permeability (L/dm².min)	Liquid Flow Rate(m³/h)
1	5	1	67	5.0	34
2	10	2	73	7.8	108
3	15	3	75	7.8	180
4	20	10	82	13	265
5	25	16	78	19	325
6	30	20	78	--	450
7	40	30	75	--	620
8	60	45	85	--	1350

Remarks: Bubble pressure test compliance with ISO 4003
Air permeability test compliance with ISO 4022, air pressure of the average permeability is 200Pa.
Test Conditions: Liquid Viscosity=1 CP﹒S, the test filter OD is 65mm, 10inches length, under 1.0bar pressure

Applications:

Chemical processing, high-temperature steam filtration, RO pre-filtration, condensate polishing, power generation, food & beverage, oil & gas produced water treatment.

Quality Assurance:

Manufactured in ISO 9001/14001/45001 certified 10,000 m² cleanroom facility. Custom lengths, micron ratings, and end-cap configurations available upon request.

Company Profile

Shanghai Pullner Filtration Technology Co., Ltd. was established in May 2011 with a registered capital of RMB 26 million. The company operates a Class 100,000 cleanroom workshop (3,000 m²) and an on-site Class 1,000 clean laboratory, integrating R&D, manufacturing, and sales of microporous membrane filtration equipment and filtration systems.

Pullner products are widely applied in microelectronics, fine chemicals, new energy, seawater desalination, biotech, and laboratory fields, including LCD panels, semiconductor processing, high-purity chemicals, condensate filtration, and reclaimed water reuse.

The company holds ISO9001 / ISO14001 / ISO45001 certificates, is recognized as a high-tech enterprise, and owns multiple patents. Pullner is also an approved vendor of Saudi Aramco.

Frequently Asked Questions

Q1: Who is the manufacturer and brand?

A1: Manufacturer: Shanghai Pullner Filtration Technology Co., Ltd. / Brand: Pullner.

Q2: Can you provide samples?

A2: Yes. We can provide 1-2 free samples for evaluation. Buyers only cover shipping. (Free samples are typically supported for future formal orders.)

Q3: What is the delivery time?

A3: Usually 5-10 working days, depending on order quantity.

Q4: Is the filtration rating nominal or absolute?

A4: Standard products are nominal. Absolute-rated filters can be customized based on your application.

Q5: Which brands can your filters replace?

A5: Compatible replacements include major brands such as PALL, 3M, PARKER, and others.

Q6: What is the MOQ?

A6: Standard MOQ is 1 piece (factory direct). For certain models or customized specs, MOQ may vary.

Pullner Workshop
