Product Details:
|
| Material: | PP, PET, Glass Fiber | Length: | 20", 40", 60" |
|---|---|---|---|
| OD: | 6" | Filtration Rating: | 1um, 2um, 5um, 10um, 15um, 20um, 30um, 50um, 70um, 100um |
| Filtration Area: | 6.6㎡ | MOQ: | 1 Piece |
| Flow Rate: | 110m³/h | OEM: | YES |
| Highlight: | Industrial High Flow Pleated Filter Cartridge,6 Inch High Flow Cartridge,Pleated High Flow Water Filter Cartridge |
||
6" Diameter Pleated PP 5 micron High Flow Cartridge Filter 99.8% Efficiency 20" 40" 60"
Features and Benefits:
* 40” outer cage is one piece, with high strength can withstand one adult weight, ensure big effective filtration area, long life;
* Gradient aperture deep polypropylene fiber filter medium, aperture along the fluid motion direction becomes smaller, levels intercept different sizes particles, which has excellent dirt holding capacity and low flow resistance;
* Outside to inside filtration direction;
* Easy installation save, less cartridge change out help customers save the labor cost;
* Integral support, high strength, high dirt holding capacity, long service life;
* Strict quality control system, complete production process flow;
* Short delivery period, production capacity>100pcs/day;
* Flexible payment method: T/T, L/C, West Union, Paypal;
* Free technical support;
* MOQ 1 piece;
* FREE sample.
Performance Specifications:
| Model | Filter Medium | Support/Drainage | End Caps | Seals Material | |
| PP | Deep pleated Polypropylene | Polypropylene | Glass Fiber Reinforced Polypropylene | NBR, Silicone, EPDM, Viton | |
| PET | Polyester | Polyester | Glass Fiber Reinforced Polypropylene | ||
| OD | 6.5" (160mm) | ||||
| Length | 20"(508mm), 40"(1016mm), 60"(1524mm) | ||||
| Micron | 1um, 3um, 5um, 10um , 15um, 20um, 50um, 70um, 100um | ||||
| Max. operating temperature | 82℃ | ||||
| Max. operating differential pressure | 3.44bar@82℃ | ||||
| Suggestion pressure for filter replacement | 2.5Bar@20℃ | ||||
| Max. flow rate | 20": 35m3/h | ||||
| 40": 70 m3/h | |||||
| 60": 110 m3/h | |||||
