Solvents API 6.6㎡ 1Um PP Pleated Filter Cartridge

Basic Information
Place of Origin: Shanghai China
Brand Name: PULLNER
Certification: FDA
Model Number: PHFM
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Carton box after poly bag. 4pcs per carton
Delivery Time: 7days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 1500pcs per week
Detail Information
OD: 6" Length: 20", 40", 60"
Material: PP, PET, Glass Fiber Filtration Rating: 1um, 2um, 5um, 10um, 15um, 20um, 30um, 50um, 70um, 100um
Filtration Area: 6.6㎡ MOQ: 1 Piece
High Light:

1Um PP Pleated Filter Cartridge


6.6㎡ PP Pleated Filter Cartridge


API High Flow Filter Cartridge

Product Description

PP High Flow Rates Filter Cartridge 1Um For API, Solvents, And Water Filtration In For Biopharm Market



Performance Specifications



Diameter 6.5" (160mm)



20" (508mm)
40" (1016mm)
60" (1524m)












Material of Construction:

Model PP PET
Filter Medium Deep Pleated PP Pleated Polyester
Support/Drainage Polypropylene Polyester
End Caps Glass Fiber Reinforced Polypropylene Glass Fiber Reinforced Polypropylene
Seals Material NBR, Silicone, EPDM, Viton


Filter Performance

Micron 1um, 3um, 5um, 10um, 15um, 20um, 50um, 70um, 100um
Max. operating temperature 82℃
Max. operating differential pressure 3.44bar@82℃
Suggestion pressure for filter replacement 2.5Bar@20℃
Max. flow rate 20": 35m3/h
40": 70 m3/h
60": 110 m3/h
