121 Degree 3.44bar Petrochemical Glass Fiber Filter Cartridge

Basic Information
Place of Origin: China
Brand Name: PULLNER
Certification: ISO9001, FDA
Model Number: PHFLH
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Export standard carton box after poly bag. 4pcs per carton.
Delivery Time: 12 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 1000pcs per week
Detail Information
Diameter: 152.4mm Filter Media: Glass Fiber
Outer Cage: Stainless Steel 304/316L Maximum Operating Differential Pressure: 3.5bar@21℃ (Inside To Outside)
Suggestion Replacement Pressure: 2.5bar @20℃ Filtration Micron: 1um~100um
Maximum Operating Temperature: 121℃ Flow Rate: 60m³/h
Filtration Area: 6.4㎡ Filtration Direction: Inside To Outside
High Light:

Petrochemical glass fiber filter cartridge

,

3.44bar water filter replacement cartridges

,

3.44bar glass fiber filter cartridge


Product Description

Glass Fiber 121℃ Pleated High Flow Filter Cartridge For Petrochemcial Water



General information

PHFLH series high flow filter cartridge use 152.4mm diameter, Glass fiber for high operating temperature 121℃ in petrochemcial industry liquis filtration. Outer cage is stainless steel 304/316L, high strength for bigger pressure.



Material Construction

Filter Media GF:  Glass Fiber
Support/Drainage Polyester
End Cap Material Fiberglass Reinforced Polypropylene



Performance

Maximum Operation Temperature

121℃

Maximum Operation Differential Pressure

3.44bar / 121°C



Flow Rate and Filtration Area

Size

(Diameter*Length)

Design Flow

(m3/hr)

Maximum Flow

(m3/hr)

Filtration Area

(㎡)

6"*20" 15 40 2.6
6"*40" 30 80 5.2
6"*60" 45 120 7.8





Performance comparison

Comparison chart of specific filter element number and corresponding filter footprint.

121 Degree 3.44bar Petrochemical Glass Fiber Filter Cartridge 0



Product Features

1. High temperature material suitable for petrochemical industry applications.

2. 6" big diameter provide bigger filtration area and high flow rate.

3. PP center core and stainless steel out cage for big pressure.
4. Much micron ratings and lengths for choosing.



                                                         Global Customers

121 Degree 3.44bar Petrochemical Glass Fiber Filter Cartridge 1

                                                                   6200㎡ Factory

121 Degree 3.44bar Petrochemical Glass Fiber Filter Cartridge 2





FAQ



Q: Are you trading company or manufacturer ?

A: Factory 6200㎡at Shanghai industry area, have our own test laboratory with advanced test facilities for filter and raw material test.

Q: How long of delivery time?

A: 100pcs, 1~3 days

    1,000pcs, 5~7days

    5,000pcs, 12~15days

    If urgent, can be negotiated.

Q: Do you provide sample ? is it free or charge ?

A: Yes, we provide FREE sample for customers, general sent out in 2days.
