The stainless steel metal filter housing is a robust pressure vessel designed to accommodate metal filter cartridges for efficient solid–liquid or solid–gas separation. Manufactured from high-quality stainless steel, this filter housing offers excellent corrosion resistance, high pressure tolerance, and long service life, making it suitable for continuous industrial operation.
Featuring a sealed cylindrical structure with quick-opening clamp or bolt closure, the housing allows easy cartridge replacement and maintenance while ensuring reliable sealing performance. It is compatible with various metal filter cartridges, including sintered stainless steel mesh, fiber felt, and powder sintered elements.
This metal filter housing is widely used to intercept suspended solids, protect downstream equipment, and improve overall system stability in chemical processing, pharmaceuticals, water treatment, food & beverage, power generation, and other demanding applications.
| Item |
Description |
| Material |
SS304 / SS316L (optional) |
| Structure |
Vertical cylindrical pressure vessel |
| Cartridge Type |
Metal filter cartridges (customizable) |
| Operating Pressure |
Up to 30 MPa |
| Operating Temperature |
Up to 600°C (depending on material) |
| Sealing Type |
Clamp / Bolt closure |
| Inlet & Outlet |
Flange / Thread / Customized |
| Surface Finish |
Polished / Sandblasted |
| Applications |
Chemical, pharmaceutical, water treatment, food & beverage, power |
Pullner Laboratory:
FAQ
1. Q: Are you a trading company or a manufacturer?
A: We are a professional manufacturer of all kinds of filter cartridges, housings and filtration systems. We provide you the total filtration solutions with our many years experience in the industry.
2. Q: May I have samples?
A: Sure, of course. Sample cost can be refunded if you place formal orders in the future.
3. Q: Can you make customized products?
A: Yes, of course. if you can provide us detailed specifications or drawings. Our mission is make customer idea on the products and provide the customer satisfied solutions.
4. Q: Can I use our own designed package?
A: Yes, size, color, logo and packaging style all can be customized.
5. Q: What's your MOQ?
A: Normally, 100PCS/item. Any trial order which is less than MOQ is warmly welcomed. If you have a trial order, please feel free to contact us so that we can make some shipping recommendation for you to save the cost based on the quantity you need.
6. Q: I am a small business owner, Can I buy from you?
A: Yes, you are warmly welcomed. To grow with our customer is our goal. We would like to grow with you together.
