Product Specifications
Material Construction
| Component |
Material |
| Filter Media |
PET |
| Support/Drainage |
G 304 Stainless Steel Outer Cage |
| End Cap Material |
Viton, Silicone, EPDM |
Performance Specifications
| Parameter |
Specification |
| Maximum Operation Temperature |
120℃ |
| Maximum Flow Rate |
40' filter: 70m³/h, 60' filter: 110m³/h |
Flow Rate and Filtration Area
| Size (Diameter*Length) |
Design Flow (m³/hr) |
Maximum Flow (m³/hr) |
Filtration Area (㎡) |
| 6"*20" |
15 |
40 |
2.6 |
| 6"*40" |
30 |
80 |
5.2 |
| 6"*60" |
45 |
120 |
7.8 |
Application Fields
- General Purpose: RO Prefiltration
- Industrial Purpose: Water pretreatment of power plant, deionized water pre-filtration
- Food and Beverage: Alcohol, Beverage
- Chemical / Petrochemical: Filtration of various acids, alkalis, solvents and kinds of chemicals
- Biopharmaceutical: Filtration of pharmaceutical, biotechnology and plasma products
Company Profile
Shanghai Pullner Filtration Technology Co., Ltd. was established in May 2011 with a registered capital of 26 million yuan. It has a 100,000-level purification workshop of 3,000 m² and a local thousand-level purification laboratory. It is a research and development, production and sales of microporous membrane filtration equipment, filtration system in one of the well-known enterprises.
The company's products are mainly used in Microelectronics, Fine chemicals, New energy, Seawater desalination, Biotech, Laboratory and other fields. Covering Liquid crystal panels, Semiconductor chips, High-purity chemicals, Raw materials, Condensate filtration, Reclaimed water reuse more than a dozen industries.
Pullner Laboratory
Our company has ISO19001, ISO14001, ISO45001 certificates, we are high-tech enterprise with multiple patent certificates. Approval vendor of Saudi Aramco.
Frequently Asked Questions
Q1: Who is the manufacturer and brand of the filter cartridges?
A1: Shanghai Pullner Filtration Technology Co., Ltd.
Q2: Can you provide samples?
A2: We offer 1-2 free samples if you place formal orders in future. Buyers only need to cover the shipping cost.
Q3: What is the delivery time?
A3: Delivery time is usually within 5-10 working days depending on the order quantity.
Q4: Is the filtration accuracy nominal or absolute?
A4: Our standard products use nominal rating. However, we can customize absolute-rated filters based on your application requirements.
Q5: Which brands can your filters replace?
A5: Our filters can be used as replacements for major brands such as PALL, 3M, PARKER, GARVER, and others.
Q6: What is the minimum order quantity (MOQ)?
A6: As a manufacturer, we accept a minimum order quantity of just 1 piece.
