Winding Type Slurry Filter Cartridge with Multi-layer PP Filter Material and Gradient Structure for 10um Removal Rating

Winding Type Slurry Filter Cartridge with Multi-layer PP Filter Material and Gradient Structure for 10um Removal Rating
Winding Type Slurry Filter Cartridge with Multi-layer PP Filter Material and Gradient Structure for 10um Removal Rating Winding Type Slurry Filter Cartridge with Multi-layer PP Filter Material and Gradient Structure for 10um Removal Rating Winding Type Slurry Filter Cartridge with Multi-layer PP Filter Material and Gradient Structure for 10um Removal Rating Winding Type Slurry Filter Cartridge with Multi-layer PP Filter Material and Gradient Structure for 10um Removal Rating Winding Type Slurry Filter Cartridge with Multi-layer PP Filter Material and Gradient Structure for 10um Removal Rating Winding Type Slurry Filter Cartridge with Multi-layer PP Filter Material and Gradient Structure for 10um Removal Rating

Large Image :  Winding Type Slurry Filter Cartridge with Multi-layer PP Filter Material and Gradient Structure for 10um Removal Rating

Product Details:
Place of Origin: Shanghai, China
Brand Name: PULLNER
Certification: ISO19001/ISO45001/ISO14001
Model Number: PHC
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: To Be Negotiable
Packaging Details: Export standard packaging
Delivery Time: 15-25 working days
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 100 Pcs Per Day

Winding Type Slurry Filter Cartridge with Multi-layer PP Filter Material and Gradient Structure for 10um Removal Rating

Description
Highlight:

Winding Type Slurry Filter Cartridge

,

High Viscosity Slurries

,

Multi-layer PP filter material

Winding Type Slurry Filter Cartridge

The PHC series filter cartridge employs a multi-layer PP filter material winding structure design, providing precise filtration for high viscosity slurries. It efficiently intercepts impurity particles while allowing effective particles to pass.

  • Gradient structure from outside to inside increases dirt holding capacity and filtration efficiency
  • Extends the filter cartridge's service life
  • Used as the inner core of a saccular filter cartridge for slurry filtration
  • Unique cage structure prevents filter material fiber shedding
Outer diameter 2.7" (69mm)
Length 10", 20", 30", 40"
Removal rating 10um, 15um, 30um
Max. operating temperature 80℃
Max. operating differential pressure 4.2 Bar @ 25℃
Max. operating differential pressure (Reverse direction) 2.1 Bar @ 25℃
Max. temperature sterilization 30 times, 30 minutes at 121℃
Material Constructions
Filter Medium PP
Support/Drainage PP
Center core/Outer Cage/End Caps PP
Seals Material NBR, Silicone, EPDM, FKM,PTFE
