Product Description:
Our Condensate Polisher offers a filtration area of 6.5㎡, making it one of the most efficient solutions available for power plant applications. With filter ratings of 1μm, 4μm, and 10μm, it effectively captures fine particulates, ensuring exceptional condensate purity and protecting downstream systems from corrosion and scaling—key factors in reducing unplanned downtime and maintenance costs.
Constructed with durable polypropylene media, the filter is highly resistant to chemical attack and designed to perform reliably under the demanding conditions of power generation environments. Its operational flow range of 3.5–4.5 m³/h makes it adaptable for various plant sizes and process needs.
Beyond fine filtration, our Condensate Polisher also serves as a condensate strainer, efficiently removing both micro-contaminants and larger debris. This dual functionality safeguards critical equipment, enhancing overall system reliability and performance. It is a vital component for ensuring clean, efficient, and uninterrupted plant operation.
Features:
- Product Name: Condensate Polishing Filter
- Filter Material: Polypropylene
- Length: 70'', 60''
- Max. Filter Temperature: 85°C
- Filter Rating: 1μm, 4μm, 10μm
- Inlet water quality: ＜2000 Ppb
Our Condensate Polishing Filter is a high-quality product designed for efficient Condensate Straining , Condensate Filtration , and Condensate Purification .
Technical Parameters:
| Product Name |
Condensate Polishing Filter |
| Max. Filter Temperature |
85°C |
| Filter Material |
Polypropylene |
| Filter Area |
6.5㎡ |
| Filter Certification |
ISO 9001, ISO45001 |
| Maximum Operating Differential Pressure |
2.8bar, 65℃ |
| Filter Rating |
1-10 um |
| Filter Size |
70'' |
| Design Flow Rate |
3.5m³/h~4.5m³/h |
| Support Core |
Reinforced Polypropylene |
| Bottom Thread |
M6, M8, M10, 3/8 |
| Key Features |
Condensate Filtration, Condensate Clarification, Condensate Polisher |
Applications:
The PULLNER PHFZ Condensate Polishing Filter is engineered for high-efficiency condensate treatment in demanding industrial environments. Available in two lengths—60" and 70"—it features a robust polypropylene construction, offering excellent chemical resistance and durability.
With a filter area of 6.5㎡, the PHFZ delivers superior filtration performance. It supports a design flow rate of 3.5–4.5 m³/h and withstands up to 3.0 bar at 65°C, making it suitable for a wide range of power and process industry applications.
Designed to remove iron oxide, copper oxide, and other particulate contaminants, this filter helps maintain condensate purity and protect downstream systems from corrosion and fouling. It is widely used in power plants, refineries, chemical plants, and other facilities where condensate quality is critical.
Key Benefits:
- High filtration efficiency with multiple micron ratings
- Durable polypropylene media for extended service life
- Easy installation and low maintenance
- Dual function as condensate filter and strainer
- Ideal for condensate clarification, polishing, and filtration
The PHFZ Condensate Polishing Filter is a cost-effective, reliable solution to ensure system integrity and operational efficiency. Contact us to learn more or request a sample.
Customization:
Model: PHFZ
Place of Origin: Shanghai, China
Certifications: ISO 9001, ISO 14001, ISO 45001
Standards Compliance: Meets ISO 9001 and ISO 45001 filter certification requirements
Material Specifications:
Filter Media: Polypropylene (PP)
Cage / Core / End Cap: Polypropylene (PP)
Max Operating Temperature: 85°C
Inlet Water Quality: Suitable for condensate with impurity level <2000 ppb
Commercial Terms:
MOQ: 100 pieces
Price: Negotiable
Packaging: Poly bag + carton box
Lead Time: 5–8 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Daily Supply Capacity: 100 pcs/day
The PHFZ Condensate Polishing Filter is designed for high-performance applications in power generation and industrial water systems. With certified quality, reliable materials, and flexible commercial terms, it offers an ideal balance of performance and value.
Packing and Shipping:
Product Packaging:
- Each condensate polishing filter will be securely packaged in a cardboard box with foam padding to prevent any damage during transit.
- The box will also include installation instructions and any necessary hardware.
Shipping:
- We offer free standard shipping within the United States.
- For international orders, shipping costs will vary based on the destination and will be calculated at checkout.
- Orders will be processed and shipped within 1-2 business days.
- Customers will receive a tracking number via email once their order has shipped.
Application Field:
1. Food and beverage 2. Sea water desalination 3. Power plant condensation 4. Petrochemical engineering
Pullner Production Process:
Company Profile:
Shanghai Pullner Filtration Technology Co., Ltd. was established in May 2011 with a registered capital of 26 million yuan. It has a 100,000-level purification workshop of 3,000 m² and a local thousand-level purification laboratory. It is a research and development, production and sales of microporous membrane filtration equipment, filtration system in one of the well-known enterprises.
The company's products are mainly used in Microelectronics, Fine chemicals, New energy, Seawater desalination, Biotech, Latoratory and other fields. Covering Liquid crystal panels, Semiconductor chips, High-purity chemicals, Raw materials, Condensate filtration, Reclaimed water reuse more than a dozen industries.
Pullner Laboratory:
Our company has ISO19001, ISO14001, ISO45001 certificates, we are high-tech enterprise with multiple patent certificates. Approval vendor of Saudi Aramco.
