Product Details:
|
| Highlight: | Low Precipitation Filter Cartridge,PFA Filter Cartridge,Chemical Corrosion Resistance Filter Cartridge |
||
|---|---|---|---|
Performance
| Filtration Rating | 0.02μm, 0.05μm, 0.1μm, 0.22μm, 0.45μm, 1μm, 3μm, 5μm, 10μm |
| Maximum Operating Temperature | 170℃ |
|
Maximum Operating Differential Pressure |
4bar/21℃ 2.4bar/80℃ |
Material Construction
| Filter Media | PFA:PTFE(Hydrophilic) |
| Support/Drainage | PFA |
| Cage/Core/End Cap | PFA |
| Seal Material | FEP |
Biological Safety
| Every 10 inches of dissolved matter | <30mg |
| Endotoxin | <0.25EU/ml/10’’ |
Ordering Information
PFA 0500 10 C5 P
| Series | Micron | Length | End Cap Type | Seal Material | ||||
| PFA | 0002 | =0.02μm | 05 | =5" | C5 | =222/Flat | P | =FEP |
| 0005 | =0.05μm | 10 | =10" | |||||
| 0010 | =0.1μm | 20 | =20" | |||||
| 0022 | =0.22μm | |||||||
| 0045 | =0.45μm | |||||||
| 0100 | =1.0μm | |||||||
| 0300 | =3.0μm | |||||||
| 0500 | =5.0μm | |||||||
| 1000 | =10μm | |||||||
