Backwashable High Flow PP Pleated Filter Cartridge with 6" Large Diameter and 1 µm to 70 µm Micron Ratings for Water Treatment

Large Image : Backwashable High Flow PP Pleated Filter Cartridge with 6" Large Diameter and 1 µm to 70 µm Micron Ratings for Water Treatment

Product Details:

Contact Now

Backwashable High Flow PP Pleated Filter Cartridge with 6" Large Diameter and 1 µm to 70 µm Micron Ratings for Water Treatment

Description

Highlight:

Backwashable PP Pleated Filter Cartridge

6" Large Diameter High Flow Filter Cartridge

1 µm to 70 µm Micron Ratings Water Treatment Filter Cartridge

Backwashable High Flow PP Pleated Filter Cartridge for Water Treatment

The High Flow Pleated Filter Cartridge is engineered for high-volume water filtration applications. Utilizing deep-pleated polypropylene (PP) or glass fiber media, this cartridge delivers exceptional high flow rates, low pressure drop, and extended service life.

Featuring a 6" (152 mm) large diameter design with no center core and dedicated inside-to-outside flow direction, contaminants and particles are efficiently retained inside the cartridge. This design enhances maintenance efficiency and extends filtration cycles while reducing the number of cartridges and housing size required, significantly lowering capital investment, installation space, and labor costs.

Key Features & Benefits

High filtration area, high flow rate - Large effective filtration area provides low differential pressure and high throughput
High dirt-holding capacity, longer service life - Multi-layer gradient pore structure (deep media design) improves particle retention and dirt loading capacity, extending replacement intervals and reducing operating costs
Wide micron ratings and multiple lengths available - Micron ratings from 1 µm to 70 µm and lengths of 20" / 40" / 60" to match diverse filtration requirements

Applications

Water Treatment

Drinking water treatment
Commercial water filtration
RO pre-filtration for seawater desalination

Industrial Filtration

Energy, coatings, graphite
Petrochemical, electroplating
Mining, machining, industrial water treatment

Power Plant

Make-up water
Condensate water
Cooling water pre-filtration

Dimensions (Nominal)

Outer Diameter (OD): 6" (152 mm)
Length: 20" (508 mm), 40" (1016 mm), 60" (1524 mm)

Materials of Construction

PP Pleated Depth Media

Filter Media: Polypropylene (PP), pleated depth
Support/Drainage: Polypropylene
End Caps: Glass Fiber Reinforced Polypropylene
Seal Materials: NBR / Silicone / EPDM / Viton

PP Melt Blown Media

Filter Media: PP melt blown
Support/Drainage: Not applicable
End Caps: Glass Fiber Reinforced Polypropylene
Seal Materials: NBR / Silicone / EPDM / Viton

Filter Performance

Micron Ratings: 1 µm, 5 µm, 10 µm, 15 µm, 20 µm, 40 µm, 70 µm
Max. Operating Temperature: 82°C
Max. Differential Pressure (Inside → Outside): 3.44 bar @ 82°C
Recommended Replacement ΔP: 2.5 bar @ 20°C
Max. Flow Rate: 40": 70 m³/h, 60": 110 m³/h
Filtration Direction: Inside to outside
