40 inches Condensate Polishing Filter with 3.5m³/h~4.5m³/h Flow Rate for Power Plants to Remove Iron Oxide
Description
| Highlight: |
3.5m³/h~4.5m³/h Flow Rate Condensate Polishing Filter Iron Oxide Removal Condensate Polisher Power Plant Condensate Application |
40 inches Condensate Polishing Filter
Ideal solution for industrial steam systems to remove impurities and ensure condensate recycling with high-efficiency filtration performance.
Product Overview
Our Condensate Polisher features a 6.5㎡ filter area, making it one of the most efficient filters available. With filter ratings of 1μm, 4μm, and 10μm, it effectively removes even the smallest impurities from condensate streams, protecting power plants from corrosion and scaling that can lead to costly downtime and repairs.
Constructed from durable Polypropylene material known for excellent chemical resistance, our filters withstand harsh power generation conditions and operate reliably for extended periods. The design flow rate of 3.5m³/h~4.5m³/h makes it suitable for diverse power generation applications.
Beyond high-performance filtration, our Condensate Polisher also functions as a Condensate Strainer, removing both impurities and larger debris to protect downstream equipment. This makes it an essential component for ensuring smooth and efficient plant operation.
Technical Specifications
| Specification |
Details |
| Product Name |
Condensate Polishing Filter |
| Filter Material |
Polypropylene |
| Available Lengths |
70'', 60'' |
| Maximum Filter Temperature |
85°C |
| Filter Rating |
1μm, 4μm, 10μm |
| Inlet Water Quality |
<2000 Ppb |
| Filter Area |
6.5㎡ |
| Design Flow Rate |
3.5m³/h~4.5m³/h |
| Max Operating Differential Pressure |
3.0bar/65℃ |
Key Features
- High-efficiency condensate straining and filtration
- Advanced condensate purification capabilities
- Durable Polypropylene construction for chemical resistance
- Multiple filter ratings for comprehensive impurity removal
- Protection against corrosion and scaling in power systems
- Suitable for high-pressure and high-temperature applications
Industrial Applications
The PULLNER PHFZ Condensate Polishing Filter is ideal for power plants, refineries, chemical plants, and other industrial facilities where condensate quality is critical. It effectively removes impurities including iron oxide, copper oxide, and other contaminants to meet required standards.
Easy to install and maintain, this filter provides a cost-effective solution for condensate clarification, polishing, and filtration applications across various industries.
Customization & Certification
Model PHFZ filters are manufactured in Shanghai, China with comprehensive certifications including ISO19001, ISO14001, ISO45001, and ISO 9001 standards. The filter construction features Polypropylene material with PP cage/core/end cap components.
Minimum order quantity: 100 units. Competitive pricing with flexible payment terms including L/C, D/A, D/P, T/T, Western Union, and MoneyGram. Supply capacity: 100 pieces per day with 5-8 working day delivery.
Pullner workshop
Packaging & Shipping
